P13USB Chip – HDMI/USB for Nintendo Switch

Description

The P13USB chip is an essential integrated circuit in managing the HDMI and USB signals of the Nintendo Switch. Located on the console's motherboard, it plays a key role in switching and transmitting data between the USB-C port and the dock, allowing display on an external screen via HDMI. In case of dock non-detection, absence of HDMI image, or partially functional USB-C port, replacing this chip can solve the issue. It is designed for experienced repairers equipped for micro-soldering.

Technical Specifications

• Reference: P13USB / P13USB-HDMI
• Type: Video/USB switching integrated circuit
• Compatibility: Nintendo Switch – all revisions (non OLED)
• Functions: HDMI, USB-C signal management, and dock detection
• Mounting: Surface Mount Component (SMC), BGA or QFN soldering
• Position: near the USB-C port on the motherboard

Advantages

• Repairs HDMI video output issues via dock
• Resolves failures related to the USB-C port (charge only, no video output)
• Allows to retain the original motherboard
• Compatible with common diagnostic tools (multimeter, hot air station)
• OEM quality, compliant with Nintendo's original specifications
• Ideal solution for specialized console electronics repairers
